BD LSRtm II Item #1803
BD LSR II : Rebuilt 4-laser, 11-color LSR II with Diva 8 Computer. Custom configurations and HTS can be quoted separately. .

Workstation: HP XW4600 computer with DiVa 8.1 software, 2 ea. 19" flat screen displays, and ink-jet printer.
Lasers: Coherent Sapphire 20 mW 488 nm, Coherent Radius 25mW 405 nm, JDSU HeNe 20 mW 633 nm and Genesis CX 100mW 355nm. Additional or substitute lasers can be quoted separately.
Fluorescence Linearity: Doublet/singlet ration of 1.95-2.0 for PI-stained chicken erythrocyte nuclei (CEN) excited with 488 nm laser.
Fluorescence Sensitivity: FITC < 80 molecules of equivalent soluble flurochrome (MESF); PE < 30 MESF
Fluorescenc Resolution: CV of PI: <3%, full G0/G1 peak for PI-stained CEN.
Beam Geometry:: Height: 20 μm; Width: 60 μm
Flow Cell Design: Rectangular Quartz Cuvette: internal cross-section, 430 x 180 mm.
Maximum Analysis Rate: Typical operation at 20,000 events/sec which requires a sample concentration of 2×10*7 cells/ml at an instrument flow rate of 60 μL/min.
Sample flow rates: Front key panel provides three modes: RUN (LO=12 μL/min; MED=35 μL/min; HI=60μL/min), STNDBY, and PRIME. The Sample Fine Adjust knob adjusts sample flow rates from 0.5-2X the rated value.
Power: 120 VAC +/- 10%, 50/60 Hz +/-2 Hz. Current: 20 amps maximum
Analyzer dimensions/weight: 62" (156 cm) w x 34" (87 cm) d x 22" (56 cm) h / 525lbs (239 kg).
Manufacture date: 2003


Pricing adjusted for alternative laser, configuration and sampler requirements .


Performed instrument decontamination and flow cell cleaning procedures. Performed any painting and silk-screening required for a like-new appearance. Replaced filters, fluidics tubing, o-rings, seals and connectors as required. Cleaned and inspected waste and sheath tanks. Set sample pressure to specifications. Confirmed all lasers performing at required power and stability. Adjusted sample flow rates for correct settings. Cleaned and aligned optics for optimum performance utilizing calibration and CST beads. Confirmed that all workstation and instrument functions meet original factory specifications. Printed all results to be included with shipment and/or faxed to purchaser for approval.

Installation by a qualified service representative quoted separately. The price will include all travel expenses and labor required to confirm proper operation at the customer's facility utilizing standard calibration procedures. Any additional time required to correct malfunctions shall be included in the quoted installation fee.

Instrument and/or applications training by a qualified representative are available for an additional fee. The quoted price includes travel and perdiem expenses when training is performed during an installation visit. Otherwise additional reimbursement for travel and perdiem expenses may be required.

Custom warranty or service contracts can be quoted separately. All components are covered unless failure is due to operator negligence. In addition, we offer unlimited telephone support for all of the products sold through Spectron Corporation regardless of warranty.

Shipping costs will be quoted separately. If the purchaser becomes the shipping agent for one of the products located in the State of Washington they could be subject to paying Washington State sales tax unless exempt. No such obligation exists if Spectron Corporation is the designated shipper to destinations outside the State of Washington. This equipment shall be packed in a sturdy double-walled box surrounded inside by 2" foam sheets on all sides. All components shall be individually protected within the same container. The box will be taped, strapped and attached to a pallet with additional strapping. Shipping will be arranged through a qualified airfreight carrier with full insurance.

Most established institutions will be approved for net-30 terms or other payment plans. Leasing or rental programs may also be available for qualified buyers with various options for an eventual purchase. Washington State customers or others arranging shipment or picking up products themselves may be subject to Washington State sales tax unless exempt. Spectron Corporation will inform prospective buyers of any such circumstance that could result in a tax liability. Otherwise, buyers would only be subject to applicable use taxes that they might be required to pay directly to their respective state.

Spectron Corporation would appreciate the opportunity to bid on a service contract covering our products as well as other flow cytometers located at your facility. Please inquire into any modifications to the listed products that would better suit your requirements. We strive for complete satisfaction.
